Frequently Asked Questions
What output voltages are available for Carlo Gavazzi power supplies?
The SPD switching power supplies offer 5, 12, 15, 24, or 48 VDC outputs, depending on the model. SPD 5, 10 and 18W come in 5, 12, 15 or 24 VDC; SPD 30 and 60W in 5, 12, 24 and 48 VDC; SPD 120W in 12, 24 and 48 VDC; and SPD 240W and 480W in 24 and 48 VDC. All SPD models have a front potentiometer to adjust the output voltage. The SPP1 enclosed panel mount supplies on this page cover 5 V to 24 V.
What power ratings do the SPD switching power supplies cover?
The SPD range covers output power ratings from 5 to 480 W. SPD 5, 10 and 18W come in a 22.5 mm wide plastic enclosure, SPD 30 and 60W in a 40.5 mm wide plastic enclosure, and SPD 120W, 240W, and 480W in a metal housing. The SPP1 enclosed panel mount supplies on this page are rated 20 W, 35 W, and 60 W.
Do power supplies include overload protection?
The SPD 120W has short circuit and overload protection, and the SPD 240W and 480W have short circuit, overload, and overvoltage protection. The SPD 5 to 60W models and the SPP1 enclosed supplies have short circuit protection.
